CRISPR/Cas9 Genome Editing Transfection Reagents

“Genome editing” or “Genome engineering” gives the ability to introduce a variety of genetic alterations (deletion, insertion…) into mammalians cells. During the past decade, zinc finger nucleases (ZFNs) and transcription activator-like effector nucleases (TALENs) were the tools of choice for genome editing technologies until the very recent discovery of CRISPR/Cas9 technology that have revolutionized the field.

Successful CRISPR/Cas9 genome editing can be performed through diverse approaches (plasmids, mRNA, nuclease, viral delivery). Accordingly, efficient nucleic acid delivery (transfection or transduction ) represents a critical step for genome editing experiments. With more than 10 years of expertise in the development of transfection reagents, OZ Biosciences offers tailored transfection solutions for CRISPR/Cas9 technology.



Transfection Reagents For CRISPR/Cas9
PolyMag Neo	Pro-DeliverIN CRISPR	RmesFect™	ViroMag R/L

    Figure 1: Adapted transfection reagents for each CRISPR/Cas9 approach.

 NEW ! Now we also offer Optimized Cas9 Nuclease.

For generation of cellular models, Cas9 and the designed sgRNA (a chimeric RNA containing all essential crRNA and tracRNA components) can be introduced into the target cells. The type II CRISPR/Cas system only needs a single Cas protein that can be expressed into target cells by: (1) plasmid transfection, (2) direct delivery of the active Cas9 endonuclease, (3) transfection of mRNA encoding for Cas9 or (4) by viral vectors transduction.



Product Name	Molecule Vector	Technology	Applications	CRISPR Cas9 Protocols
PolyMag Neo	Plasmid DNA	Magnetofection	Primary and hard-to-transfect cells
Pro-DeliverIN CRISPR	Protein	Lipofection	All cells
RmesFect™	mRNA	Lipofection	All cells
ViroMag R/L	Virus	Magnetofection	All cells including primary and hard-to-transfect cells

Genome Editing with CRISPR/Cas9

In 2013, four groups demonstrated that CRISPR/Cas9 >associated with guide RNA can be used for gene editing [2-5]. Based on the type II CRISPR/Cas9 mechanism, researchers created a single guide RNA (sgRNA), which is able to bind to a specific dsDNA sequence. This resulted in double strand breaks (DSB) at target site with: (1) a 20-bp sequence matching the protospacer of the guide RNA and (2) a protospacer-adjacent motif (PAM) 3 bp downstream NGG sequence. CRISPR/Cas9-mediated genome editing thus depends on the generation of DSB and subsequent cellular DNA repair process. The presence of DSB in the DNA generated by CRISPR/Cas9 leads to activation of cellular DNA repair processes, including non-homologous end-joining (NHEJ)-mediated error prone DNA repair and homology-directed repair (HDR)-mediated error-free DNA repair. Insertions and deletion mutations at target site generated by NHEJ and HDR allow disrupting or abolishing the function of a target gene. Moreover, modifications in this system can also be used to silence gene, insert new exogenous DNA or block RNA transcription.



How does CRISPR/Cas9 work?

CRISPR/Cas9 system originates from bacteria in which it provides acquired immunity against invading foreign DNA via RNA-guided cleavage [1]. Bacteria collect “protospacers”, short segments of foreign DNA (e.g. from bacteriophages) and integrate them into their genome. Sequences from CRISPR genomic loci are then transcribed into short CRISPR RNA (crRNA) that anneal transactivating crRNA (tracrRNAs) to destroy any DNA sequence matching the protospacers. After transcription and processing, crRNA first complexes with Cas9 and tracrRNA and then bind its target sequence onto DNA. Both R-loop forms and DNA strands are cut. crRNA is used as a guide while Cas9 acts as an endonuclease to cleave the DNA (figure 1).



Figure 2: The CRISPR-Cas9 nuclease programmed with sgRNA.

Upon binding the sgRNA guide (tracrRNA-crRNA) specifically targets a short DNA sequence-tag (PAM) and unzips DNA complementary to the sgRNA. sgRNA–target DNA heteroduplex, triggering R-loop formation results in a further structural rearrangement: Recognition (REC) and Nuclease lobes (NUC) undergo rotation to fully enclose the DNA target sequence. Two nuclease domains (RuvC, HNH) each nicking one DNA strand, generate a double-strand break. Structurally, REC domain interacts with the sgRNA, while NUC lobe drives interaction with the PAM and target DNA.

Various Cas9-based applications:

• Indel  (insertion/deletion) mutations.
• Specific sequence insertion or replacement.
• Large deletion or genomic rearrangement (inversion or translocation).
• Fusion to an activation domain :
  • Gene Activation.
  • Other modifications (histone modification, DNA methylation, fluorescent protein).
  • Imaging location of genomic locus.

CRISPR/Cas9 advantages over ZFNs and TALENs

CRISPR/Cas9 can easily be adapted to any genomic sequence by changing the 20-bp protospacer of the guide RNA; the Cas9 protein component remaining unchanged. This ease of use presents a main advantage over ZFNs and TALENs in generating genome-wide libraries or multiplexing guide RNA into the same cells.

• ZFNs and TALENs are built on protein-guided DNA cleavage that needs complex protein engineering.
• CRISPR/Cas9 only needs a short guide RNA for DNA targeting.
• CRISPR/Cas9 allows using several gRNA with different target sites: simultaneously genomic modifications at multiple independent sites [2].
• Accelerates the generation of transgenic animals with multiple gene mutations [6].

CRISPR/Cas9 system presents a versatile and reliable genome editing tool to facilitate a large variety of genome targeting applications. CRISPR/Cas9 components comprise an endonuclease and a sgRNA that can be delivered into cells under various forms (i.e. plasmid, mRNA, nuclease, virus).

References

1. Wiedenheft B, et al. RNA-guided genetic silencing systems in bacteria and archaea. Nature 482, 331-338.
2. Cong L, et al. Multiplex genome engineering using CRISPR/Cas systems. Science. 2013;339 (6121):819-823.
3. Mali P, et al. RNA-guided genome engineering via Cas9. Science. 2013;339 (6121):823-826.
4. Jinek M, Chylinski K, Fonfara I, Hauer M, Doudna JA, Charpentier E. A programmable dual-RNA-guided DNA endonuclease in adaptive bacterial immunity. Science. 2012;337 (6096):816-821.
5. Cho SW, Kim S, Kim JM, Kim JS.  Targeted genome engineering in human cells with the Cas9 RNA-guided endonuclease. Nat Biotechnol. 2013;31(3):230-232.
6. Wang H, et al. One-step generation of mice carrying mutations in multiple genes by CRISPR/Cas-mediated genome engineering. Cell. 2013;153 (4):910-8.
